Features
Features:
- Frame Configuration – Available in 10 to 40-ft. widths. Single roller system with four tines per row. Standard 7 ½” tine spacing.
- Wing Down Pressure Valve – Standard on all Folding Wing models. Valve is pre-set at the factory but can be easily adjusted in the field to suit varying ground conditions.
- Trunnion Bearing & Mounting Bracket – Heavy-duty 50mm bearing standard on all AWST and AWFT machines. No-lube bearings are designed for severe service applications.
- C-Flex System – Standard on all AWST and AWFT machines. Designed to protect rollers from impact and shock loads.
Options:
- Rolling Baskets – Available with either 3-Bar Coil Tines with 14” Single Roller.
- Rear Tool Bar – AWST and AWFT frames are designed to accept an optional rear tool bar, allowing the user to attach his own finishing tools.
- Pull-type Wheel Kits – Designed to convert the machinery into a “trail” unit with tires rearward.
- Scraper System for Rollers – For units working in challenging or high-residue conditions.
- Ballast Blocks – For hard compacted ground conditions, ballast blocks are available in 550 and 750-lb. weights.
- Lighting Kit – Includes two lights and two universal mounting brackets and harnesses.
Benefits:
- Versatility – Quick-adjust feature allows you to easily vary the roller swing angle to meet your tillage and cropping demands.
- Value – Can be used full season and is readily adaptable to no-till, minimum till, and conventional till practices.
- All-Season – Ideal in the springtime for warming and drying soils. Post-harvest use allows your soils to breathe and promotes better residue breakdown.
- Dependable – All components chosen for strength and durability to withstand the demands of day-to-day farming.
- Outstanding Yields – Get top yields with lower input costs. It all comes down to the bottom line.
Specs
AWFT FRAME CONFIGURATIONS - Folding Frame | |
C-FLEX Single Row AerWay ® - available in 7.50" effective tine spacing | |
Model Number | AWFT300 |
Cultivation Width | 30' |
Travel Width | 15' 9" |
# of Tines | 192 |
Weight | 7149 lbs |
HP Required | 180-300 |
-
